The machine produces durable, UV-resistant agricultural films for ground, greenhouse, and weed control, with heat preservation, moisture retention, and insect prevention to boost output.
Product parameters
| Model | SJ75/90/75-2600 | |
| BASIC PARAMETER | Suitable Materials | LDPE，LLDPE,mLLDPE,Neutral material |
| Film Width | 1400-2400mm | |
| Film thickness | 0.03-0.15mm | |
| Maximum output | 450-550kg/hr | |
| EXTRUDER | Screw diameter | ф 75；ф 90； |
| Aspect ratio | 1:32 | |
| Main motor power | 75kw×2 90kw×1 | |
| Reduction box model | 250×2 315×1 | |
| Die head diameter | ф 550mm | |
| Air ring diameter | ф 590mm | |
| Blower | 22kw | |
| Screen changing method | Dual-station manual quick screen change | |
| TAKE UP UNIT | Roller width | 2600mm |
| Take-up speed | 5-90m/min | |
| Take-up motor | 3kw | |
| Roary type | Horizontal type | |
| EPC correction | Centering or edge alignment Ultrasonic photoelectric type | |
| WINDIND UNIT | Winder Type | Automatic central gap winder |
| Automatic tension system | Auto Tension control | |
| Winding motor power | 3kw | |
| Winding speed | 5-90m/min | |
| CONTROL UNIT | Electrical part | Schneider |
| Control system | Austria B+R system or China brand systm | |
| Inverter | Yaskawa、Delta、Inovance、Slanvert（According to customer requirements） | |
| (L×W×H) | Dimension | 15mx9.5mx13.5m/14.5m |
